Water Drop type Hammer Mill
Fish feed Hammer mill in fish feed pellet factory
Hammer crusher machine is a special equipment to break large materials into fine powder, Raw materials in feed crusher are crushed into suitable particle sizes for feed mixer procession. Final size of materials can be controlled by inserting a screen with different sized holes, animal feed crushing machine is mainly employed in the farm, middle sized feeding factory or for family use.
Specification of hammer mill for the aquatic plant
Hammer mill is suitable for powder making. We can adjustment the inside hammers, mesh and rotating speed of shaft to get required output size from 0.6-1.5mm or 1-2.5mm for fish feed pellet making, other bigger sizes are optional by your choice. This machine got good reputation for the animal feed pellet factory and aquaculture plant.
Working principle of the hammer mill
When material enters the crushing chamber, it will be crushed to the required particle size by the high-speed rotating hammers with the function of repeated impact, friction ,and collision. The qualified sized will discharge through the mesh.
Feed crushing machine featured advantages
1. The U-type additional punching groove is adopted at the bottom of the hammer mill chamber, which greatly improves the crushing efficiency and production efficiency. Quick open the operating gate, elastic pressure screen, convenient maintenance and replacement panel.
2. Rotor checking by dynamic balance, which is low noise in smoothly running.
3. Safe and environmental protection, nested seal, dust-free, improve its working environment.
4. SKF bearing with longer service life and cost less for maintenance.
5. Full-open operating gate, adjustable external tension for mesh tube, easy for repair and replace the mesh, the mesh can be customized.
6. Optional - impeller feeder, easy to operate, avoid blockage of the machine.
| Model | SFSP56*36 | SFSP56*40 | SFSP66*60 | SFSP66*80 | SFSP66*100 |
| Power （kW） | 22 | 37 | 55/75 | 90/110 | 132/160 |
| Capacity （t/h） | 1-5 | 2-8 | 4-12 | 15-25 | 20-30 |
